Inside measuring probe Marameter 844 Kk
| Product number: | 4473068 |
|---|
844 Kk Inside measuring probe
Nominal size: 20 mm
Measuring range : 19.4 - 20.6 mm
Design: for general applications
Material type:
Material Contact surface: hard chrome plated
Nominal size: 20 mm
Measuring range : 19.4 - 20.6 mm
Design: for general applications
Material type:
Material Contact surface: hard chrome plated
Product price
97,00 €
Application
Standard model
- For indicating measurment of diameter and testing for roundness and conicity of bores
- Especially suitable for testing batches
- Determine the reversal point by rocking in the bore
Product features
- Measuring head made of hardened steel, hard chrome plated
- Constant measuring force as a result of built-in spring, eliminating user influence
- Extensive modular system is composed of measuring head, transfer needle, holder, depth extension, right angle attachments and setting rings
The minimum set of a measuring instrument consists of: Measuring head, transfer needle and holder plus indicator unit
Material Contact surface
hard chrome plated
Marameter 844 Kk | Art. no. 4473068
